Compact single-fan unit
The 4, 5 and 6 HP compact models carry the technology of the twin-fan unit in a smaller, lighter body.
LG · VRF Systems
LG MULTI V S
A compact VRF that fits on an apartment balcony. One single-fan outdoor unit from 4 HP serves up to 23 indoor units across a home or small office.
4–14HP
23indoor units max.
R1scroll compressor
Outdoor capacity
Key features
Saves floor space
Slim, light, side-discharge outdoor units in compact and standard models.
R1 scroll compressor
LG's revolutionary R1 compressor, made at LG's Pune factory.
Flexible design
Wide indoor unit line-up with flexible piping directions.
Dual sensing smart load control
Available with the LG remote controller.
Residences & small offices
4–6 HP single-phase models run on a standard home supply.
Why it stands out
1 fan
23 rooms
One system, whole home
Mix ceiling cassettes, 1-way cassettes and wall units on one outdoor unit.
Ocean Black Fin
Coastal-grade coil
Acryl, epoxy and melamine resin layers under a hydrophilic film resist salt and pollution.
LG MV app
Service from a phone
Engineers check cycle data, installation and faults on the LG MV app. Home owners use ThinQ with the PWFMDD200 Wi-Fi modem.
Specifications
| Type | Air-cooled VRF · heat pump & cooling only |
|---|---|
| Heat pump | 4, 5, 6 HP (1Ø 220 V or 3Ø 380 V); 8, 10, 12 HP (3Ø, twin fan) |
| Cooling only | 5, 6 HP (1Ø 220 V); 14 HP (3Ø 380 V) |
| Capacity range | 4 ~ 14 HP (12.1 ~ 38.0 kW) |
| Indoor units | Up to 23 |
| Compressor | LG R1 scroll |
| Discharge | Side discharge |
| Connectivity | ThinQ via PWFMDD200 Wi-Fi modem, LG MV, 3rd-party home network interlock |
